CHARACTERISTICS
Thrust until 600 000 N
Double Acting and Single Acting – Fail Safe Closing or Opening
Fluid media : air, water, oil, natural gas
Temperature of use : -20°C to +80°C (on demand : -60°C / + 140°C)
Cylinders sizes : Ø 90 mm to 1100 mm
Strokes : until 750 mm
SUPPLY PRESSURE
2.5 barg to 140 barg for pneumatic application
30 barg to 400 barg for hydraulic application
STANDARD DESIGN
Carbon steel cylinder with Epoxy PTFE coating (others on demand)
Carbon steel flanges
High alloy tie rods
Piston rods hard chromed carbon steel
Topwork acc. to ISO 5211
OPTIONS
Control systems
Manual override (hydraulic hand pump or handwheel)
Adjustable end stops (Opening and/or Closing)
Limit switches
Electro-hydraulic
Fire Proofing
Special studies acc. to your request
Subsea
